Self-Forming Silicon Nitride Nanomask and Its Applications

Capa

Citar

Texto integral

Acesso aberto Acesso aberto
Acesso é fechado Acesso está concedido
Acesso é fechado Somente assinantes

Resumo

Self-forming wave-ordered structure arises on the surface of single-crystal or amorphous silicon during its sputtering with an inclined beam of nitrogen ions. The wave-ordered structure is a solid nanomask, a dense array of silicon nitride nanostripes with a period in the range 30–90 nm. The induced spatial coherence of the nanomask due to the formation of sharp geometric boundaries on silicon surface in the areas of ion bombarded is considered. Based on the nanomask and etching processes (wet and dry), various nanostructures are formed, which are used in different high technologies. Prototypes of solar cells, nanowire grid polarizers, and nanostructured silicon substrates for surface-enhanced Raman spectroscopy have been created. The results of a study of the initial stages of lysozyme protein crystallization on nanostructured silicon substrates are presented.
