Characteristics of the charge-discharge cycle of a hydrogen-bromine battery with an IrO2/TiO2 cathode on a titanium felt in the full capacity utilization mode

封面

如何引用文章

全文:

开放存取 开放存取
受限制的访问 ##reader.subscriptionAccessGranted##
受限制的访问 订阅存取

详细

Сyclic charge/discharge process of a hydrogen-bromine battery has been studied. Porous titanium felt coated with mixed IrO2 – TiO2 oxide coverage in contact with aqueous HBr/Br2 solution has been used as positive (“cathode”) electrode. Hydrogen gas diffusion electrode with Pt/C catalytic layer served as negative electrode while the hydrogen ion is transferred between them via perfluorinated sulfocation-exchange membrane GP-IEM 103. Morphology, phase, and chemical composition of the cathode material have been characterized using scanning electron microscopy with X-ray spectral microanalysis, Raman spectroscopy and X-ray photoelectron spectroscopy. Condition for switching between the charging and discharging stages within each cycle (based on upper limit for voltage) has been chosen to minimize the amount of bromide and polybromide anions relative to molecular bromine formed at the end of the charging stage (oxidation of Br–), instead of the traditionally used approach which includes only partial conversion of bromide to bromine in order to increase the stability of the latter in the form of polybromide complexes. Charge-discharge tests of the hydrogen-bromine battery are carried out in the galvanostatic mode at three current densities: 25, 50 and 75 mA/cm2. Comparison of the charge and average voltage values in the course of the electrical energy generation (discharge stage) and storage (charge stage) shows that the highest efficiency of the cycle is achieved at the current density of 50 mA/cm2. This value of the charge/discharge current density also corresponds to the maximal use of the redox capacity of the electrolyte. It has been found that the stability of the mixed-oxide cathode material used in contact with bromine compounds in acidic environment exceeds significantly that of the carbon paper. The main reason of the decrease of the battery capacity from cycle to cycle is the molecular bromine absorption by elements of the system in contact with the catholyte: components of the membrane-electrode assembly (MEA), pipelines and elements of the pump that ensures circulation.
