卷 50, 编号 3 (2024)

The results of experiments at the T-10 tokamak using lithium capillary-porous structures are presented. It is shown that lithium sputtering under conditions of graphite diaphragms can significantly reduce deuterium recycling and the level of impurities in the plasma. At the same time, recycling increases significantly five discharges after the start of the day of the experiment, and the effect of reducing the level of impurities persists for 150—300 discharges. The results of using a capillary-porous structure with lithium filling as a movable rail diaphragm in the T-10 configuration with tungsten main diaphragms are presented. The introduction of a lithium diaphragm into the SOL region makes it possible to reduce recycling and obtain discharges with an effective plasma charge approaching unity. In this case, the effect increases as the lithium sputtered in the chamber is accumulated. It is shown experimentally that a capillary-porous structure with lithium filling can be used as a main diaphragm with longitudinal plasma heat fluxes up to 3.6 MW/m². However, a necessary condition is the complete impregnation of the porous structure with lithium and the prevention of extrusion of lithium into the discharge as a result of the interaction of the current flowing to the diaphragm with the toroidal magnetic field. Experiments have shown that to obtain discharges with a small lithium admixture, a strong gas injection of deuterium or impurity is required to reduce the temperature of the plasma periphery and effective cooling of the diaphragm below 450 Å°C. Otherwise, the diaphragm transfers into a strong evaporation mode with high lithium flows, which lead to a significant increase in the lithium concentration in the plasma. Strong evaporation reduces the heat inflow and stabilizes the diaphragm temperature.

mail: nrcki@nrcki.ru

The canonical profiles transport model (CPTM), whose coefficients were determined from the T-10 tokamak database with a standard magnetic field B_T = 2.3—2.5 T, has shown its robustness in ohmic regimes with a reduced magnetic field B_T = 1.55—2.1 T. We used the CPTM for predictions of radial profiles and dependences of the electron and ion temperatures and the energy confinement time on the average plasma density for the T-15MD tokamak at the initial stage of its operation: the ohmic regime in a circular limiter configuration with B_T = 1.0—2.0 T and plasma current I_p < 1 MA.

This paper reports on the generation of a directed flux of electromagnetic radiation with an energy content of 10 J in the frequency range of 0.2—0.3 THz at a microsecond pulse duration in a beam-plasma system. The flux is generated when a relativistic electron beam (REB) pumps electron plasma waves in a magnetized plasma column. In the described experiments, this fundamentally new approach to generate terahertz radiation was carried out at the GOL-PET facility in the conditions of varying the beam current density and the plasma density in the appropriate ranges of 1—2 kA/cm² and 10¹⁴—10¹⁵ cm⁻³. From the comparison of the flux energy spectrum measured experimentally in the frequency range 0.15—0.45 THz with the calculated one obtained using the previously proposed model of radiation generation in a beam–plasma system, it was shown that this process occurs through resonant pumping by REB of precisely the branch of upper-hybrid plasma waves. Mastering this new method to generate terahertz radiation opens the prospect of its use to obtain multi-megawatt radiation fluxes in the frequency range up to 1 terahertz and higher. For such a development approach the most promising beam for pumping plasma oscillations seems to be a kiloampere REB generated in a linear induction accelerator.

The results of experiments are presented on the deposition onto silicate glasses of thin refractorymetal- films: molybdenum, tantalum and tungsten. The technique used for manufacturing films was based on the deposition of metal-containing plasma formed when exposing the surface of foils made of refractory metals to high-power plasma and ion pulses. For generation of such pulses, the facility of plasma focus type was used, which makes it possible to obtain ion beams and plasma flows with the energy flux density in the range of 10¹⁰—10¹² W/cm². The most intense central part of the ion-plasma flow was separated using metal diaphragms with aperture diameters of 2.5, 3.5, and 4.5 mm. Metal Mo, Ta and W films with dimensions of ∅ 3—5 mm were obtained on the surfaces of glasses. Metal films are characterized by good adhesion, since they coalesce with the glass surface. It was discovered that the planarity of films becomes violated due to the drift of molten metal particles under the glass surface. The relief of films is non-uniform, which can be explained by the presence of micrometer-sized metal particles in the plasma flow.

Astrophysical jets are collimated plasma outflows observed in diverse astrophysical settings covering seven decades of spatial scale and twenty decades of power, which, nevertheless, share many common features. This similarity over wide range of scales indicates a common core of physics underlying this phenomenon, leading to considerable interest in observational, theoretical and numerical studies. Laboratory astrophysics experiments for simulating astrophysical jets are premised on this common core of physics responsible for multi-scale similarity of jets remaining valid down to laboratory spatial scales of millimeters. Jets formed after the disassembly of the non-cylindrical z-pinch formed in a plasma focus installation have recently been subjects of observational studies. They offer an important complementarity to the main lines of investigations in two respects. Firstly, the multi-faceted role of gravity, radiation, nuclear reactions and related astrophysics is eliminated retaining only a rapid implosion of a compact plasma object in a magnetohydrodynamic environment as a common feature. Secondly, observations can be made using techniques of laboratory plasma diagnostics. In this paper, we report preliminary results regarding presence of poloidal magnetic flux associated with the jets lasting long after the pinch disassembly. This is significant in the context of uncertainty regarding the origin of poloidal magnetic field postulated in several MHD models of astrophysical jet phenomena. Evidence indicating presence of a radial component of electric field suggests existence of plasma rotation as well. These results suggest that more refined experiments can provide insights into the astrophysical jetting phenomena not available from observational astronomy techniques.

The radiation of signal by the plasma asymmetrical vibrator antenna is studied for two methods of its excitation. Earlier, it was shown that the 2nd and 3rd harmonics of the input signal frequency in the radiation spectrum of the plasma antenna are 10—20 dB stronger than those of a metal antenna with the same geometry. In this work, we study experimentally and by computer simulations the effect of the method of excitation of the plasma asymmetrical vibrator antenna on the spectral characteristics of the signal that it radiates. For the two excitation methods of the antenna, through an electrode and through a coaxial coupler, it was shown that the strength of the signal components at the frequency of the radiated signal and its multiple harmonics is different. The introduction of the coaxial coupler in the antenna excitation scheme allowed us to improve the coupling at the input signal frequency and decrease its components at the 2nd and 3rd harmonics. For the plasma antenna with the coaxial coupler, the difference between the 1st and 2nd harmonics was increased by almost 6 dB, and between the 1st and the 3rd ones by almost 20 dB compared to the antenna excitation scheme through the electrode.

We present a numerical model of the main stage of a lightning discharge. Within the framework of the developed model, evolution of parameters of the current channel upon the return stroke (the lightning main stage) is described by the system of equations governing conservation of mass, momentum, total energy, along with the transmission-line equations for determining the electric potential and the total current in each channel cross section. The main characteristics of lightning at the stage of the return stroke detectable experimentally, such as gas heating in the channel to temperatures in the range of 10–40 kK, the fundamental possibility of propagation of the potential-gradient wave at a speed varying from several hundredth to several tenths of the speed of light, and the possibility of the return-stroke wave propagating a relatively long distance without substantial attenuation, are demonstrated numerically. The conclusion that the developed physical and numerical model of the lightning discharge describes physical processes that occur under real conditions qualitatively correctly can be drawn based on the results on simulation of lightning discharges of various intensity.
