Разделение промышленных аммиаксодержащих газовых смесей с помощью полимерных мембран

Cover Page

Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription Access

Abstract

Развитие аммиачной промышленности и направления применения аммиака как перспективного носителя водорода невозможно без исследований технологий разделения аммиак-содержащих газовых смесей (NH3–H2–N2). Мембранное газоразделение — перспективное направление для решения данной задачи. В настоящем обзоре представлена информация по существующим разработкам в области водород- и аммиак-селективных газоразделительных мембран, с фокусом на синтетических полимерных материалах. Рассмотрен широкий спектр материалов различных типов (иономерные материалы, полиолефины, поликонденсационные материалы, фторсодержащие полимеры, силоксановые полимеры, гибридные мембраны), представлены сведения по коэффициентам проницаемости NH3, H2, N2, а также по идеальным селективностям пар этих газов. Продемонстрировано, что наиболее удовлетворительными транспортными и разделительными характеристиками обладают иономерные материалы, а также мембраны на основе новых типов полиимидов.
